RO system is raw water through precision filter, granular activated carbon filters, activated carbon filters, compression, then through the pump pressure, the use of reverse osmosis membrane pore size 1/10000μm make a higher concentration of water into low concentration of water, while the industrial pollutants, heavy metals and other impurities in the water mixed with a large number of full isolation, to achieve the required physical and chemical indicators for drinking and hygiene standards, outputs to clean pure water is the best choice of body replenish water quality. It's also a good choice for chemical It is key equipment of pure water plant.
Source-verified operational parameters and mechanical specifications for this equipment configuration.
| Parameter | Specification Value |
|---|---|
| Pure Water Stage | Single satge | Double stage | Double stage with EDI |
| Material | 304 stainless steel/PVC |
| Pre-treatment Filter | Quartz sand, Activated carbon and Softened resin |
| Specification | 250L/H 500L/H 1000L/H 2000L/H 3000L/H 5000L/H |
| Osmosis Membrane | CSM/DOW |
| Conductivity | 10 μS/cm | 3 μS/cm | 0.1μS/cm |
| Raw Water | Tap water/Underground water |
| Control Way | Push button control/Touch screen |
Detailed inspection of verified station components, drives, and sanitation assemblies.
Pure Water Stage Single satge Double stage Double stage with EDI Material 304 stainless steel/PVC Pre-treatment Filter Quartz sand, Activated carbon and Softened resin Specification 250L/H 500L/H 1000L/H 2000L/H 3000L/H 5000L/H Osmosis Membrane CSM/DOW Conductivity 10 μS/cm 3 μS/cm 0.1μS/cm Raw Water Tap water/Underground water Control Way Push button control/Touch screen
Configure this unit to your formula volume, container type & speed requirements.
Connect with Dalipco machinery specialists to review changeover parts, line integration, throughput validation, or request formal quotation terms.
