Advantages of Automatic Multifunctional Labeling Machine ● Broad Industry Applicability This labeling machine demonstrates remarkable versatility, catering to a vast spectrum of industries.
Advantages of Automatic Multifunctional Labeling Machine
Broad Industry Applicability
This labeling machine demonstrates remarkable versatility, catering to a vast spectrum of industries. It is well - equipped to handle the labeling needs of food, condiments, pharmaceuticals, liquor, oils, cosmetics, and more. Whether it's the delicate packaging requirements of high - end cosmetics or the strict regulatory - compliant labeling in the pharmaceutical industry, this machine can adapt, making it an ideal choice for diverse manufacturing sectors.
High - Quality Components
Flexible Operation for Small - Batch Production
Designed with small - batch and diversified product production in mind, this machine is highly suitable for single - machine and single - operator use. It offers the flexibility to quickly switch between different label designs, bottle sizes, and product types. This is particularly beneficial for small - to - medium - sized enterprises or for companies with frequent product line changes, as it allows for cost - effective production without the need for large - scale, complex setups.
Comprehensive Functionality
Adjustable Labeling Parameters
The labeling position, height, and angle are all fully adjustable. This adaptability allows for customization according to different bottle shapes, sizes, and label requirements. Whether it's a tall, slender bottle that needs a label placed at a specific height or a uniquely shaped bottle that requires an angled label application, this machine can be easily configured to meet these demands, ensuring professional - looking and compliant labeling.
Seamless Production Line Integration
Capable of being connected to a conveyor belt, this machine can be seamlessly integrated into existing production lines. This integration enhances production efficiency by enabling continuous labeling operations. It can work in harmony with other packaging equipment, such as filling machines and capping machines, creating a streamlined packaging process. This not only saves time but also reduces the risk of human - error associated with manual transfer between different production.
The labeling heads are powered by Japanese Panasonic servo motors. Renowned for their high precision, reliability, and smooth operation, these motors ensure accurate label dispensing. They can precisely control the speed and position of label application, resulting in consistently perfect labeling, even for complex or high - speed production runs.
All photoelectric sensors used are top - tier products sourced from Japan and Germany. These advanced sensors offer high sensitivity and stability. They can accurately detect the presence, position, and movement of bottles and labels, enabling seamless and error - free labeling operations. Whether in a high - humidity environment in a food production facility or a dust - free cleanroom in a pharmaceutical plant, these sensors perform optimally.
The integration of a German Siemens PLC with a human - machine interface provides a robust and intelligent control solution. The Siemens PLC is known for its high - speed processing capabilities, reliable data handling, and flexibility in programming. Coupled with an intuitive human - machine interface, operators can easily set parameters, monitor the labeling process, and make real - time adjustments, ensuring efficient and trouble - free operation.
The machine is equipped with a series of essential mechanisms. The bottle alignment mechanism ensures that each bottle is in the correct position for labeling, minimizing errors. The bottle - dividing mechanism smoothly separates bottles, preparing them for the labeling process. The labeling mechanism itself applies the labels accurately, while the bottle - flattening mechanism ensures that the labels are evenly adhered. Additionally, the counting mechanism keeps track of the number of labeled bottles, facilitating production monitoring and quality control.
Source-verified operational parameters and mechanical specifications for this equipment configuration.
| Parameter | Specification Value |
|---|---|
| Suitable Bottle Shape | Round, flat, oval, square, ect.(round bottle labeling position is optional) |
| Labeling Speed | 40-100bottles/minute |
| Bottle Outer Diameter(customizable) | 30-120mm |
| Bottle Height(customizable) | 30-350mm |
| Suitable Label Height(customizable) | 15-200mm |
| Power | 3000W |
| Voltage | 1ph AC 220V/110V 50/60Hz |
| Dimension(L*W*H) | 3000*1400*1750mm |
| Weight | 520kg |
Detailed inspection of verified station components, drives, and sanitation assemblies.
Wide Product Adaptability: Whether it is a round bottle, a flat bottle, or a square bottle, this labeling machine can handle them accurately. It can achieve full - circle labeling and half - circle labeling for round bottles, as well as single - side and double - side labeling for flat bottles and square bottles. In the cosmetics industry, it can label various products such as round - bottle perfumes, flat - bottle lotions, and square - bottle creams. In the food industry, it can carry out high - efficiency labeling operations on round cans, square sauce boxes, and flat - shaped beverage bottles.
High - Efficiency Labeling Speed: The labeling speed of this labeling machine can reach 100-200 pieces per minute, which can greatly improve production efficiency and meet the large - scale production needs of enterprises. Its fast labeling speed enables products to quickly enter the next production process, reducing the production cycle and enhancing the market competitiveness of enterprises.
High - Precision Labeling Quality: The labeling accuracy of the equipment can reach ±1.0mm. Through advanced sensors and a precise control system, it can ensure the accurate position of the label on the product. At the same time, the two - stage label - covering mechanism is equipped. The first stage ensures the labeling accuracy, and the second - stage extrusion - type label - covering effectively eliminates air bubbles and ensures the tight fit of the head and tail of the label, making the label flat and firm without wrinkles and bubbles, which greatly improves the appearance quality of the product.
