● High Labeling Precision The bottle‑separating device cooperates with label‑dispensing mechanism to minimize position error.
High Labeling Precision
The bottle‑separating device cooperates with label‑dispensing mechanism to minimize position error. Label positions remain consistent during mass continuous production.
Premium Labeling Quality
Silicone label‑covering roller compresses labels tightly. Labels are bubble‑free and wrinkle‑free, supporting single‑side and double‑side labeling for round bottles.
Easy operation
Touch‑screen HMI, parameters such as labeling speed and label length can be set directly. Operators can master it quickly to save labor cost.
Wide Compatibility
Easy mechanical adjustment fits various round bottles and label sizes, widely used in cosmetic, daily‑chemical, food and pharmaceutical industries.
Easy Maintenance & Adjustment
Modular mechanical structure, each functional unit can be adjusted independently. Quick size change‑over between different products, convenient for daily inspection and maintenance.
Source-verified operational parameters and mechanical specifications for this equipment configuration.
| Parameter | Specification Value |
|---|---|
| Name | Automatic Round Bottle Labeling Machine |
| Voltage | 220V/50Hz (Customized) |
| Power | 1.5KW |
| Production capacity | 20-40pcs/min(depends on bottle size) |
| Labeling Accuracy | ±1mm |
| Roll inside diameter | φ76mm |
| Roll outside diameter | φ370mm |
| Dimension(L*W*H) | 3000*1500*1750mm |
Detailed inspection of verified station components, drives, and sanitation assemblies.
Human‑machine touch control panel enables simple and intuitive operation. All working parameters such as labeling speed and label length can be directly set on screen. Real‑time running data is displayed for easy monitoring and accurate adjustment, helping operators finish parameter setup quickly.
Equipped with high‑elastic silicone rollers, this label‑covering mechanism drives round bottles to rotate steadily. It presses and rolls labels tightly against bottle surfaces to eliminate air bubbles. It supports single‑sided and double‑sided labeling, delivering flat and wrinkle‑free labeling results for round containers.
The bottle‑separating device accurately spaces incoming bottles on the conveyor. It keeps consistent bottle‑to‑bottle distance during production, effectively avoids bottle crowding and overlapping, reduces labeling position errors and improves overall labeling stability.
Professional label‑dispensing mechanism includes label unwinding, guide rollers, peel‑off plate and liner rewinding unit. It feeds labels smoothly and peels labels precisely from backing paper. Height and horizontal position are adjustable to fit various label sizes for different round bottles.
Configure this unit to your formula volume, container type & speed requirements.
Connect with Dalipco machinery specialists to review changeover parts, line integration, throughput validation, or request formal quotation terms.
